Power Output

100W RMS into 8 Ohms @ <1%THD+N, 155W RMS into 4 Ohms @ 1kHz <1%THD+N

Amplification

Class-A/B

DAC

ES9018K2M

Preamp Mode

Yes

Frequency Response

<3Hz – >40kHz +/-1dB

Toroidal Transformer

Yes

Bi-wiring possible

Yes

Analogue RCA Inputs

4 pairs

Balanced XLR Input

1 pair

S/PDIF TOSLINK Input

2

S/PDIF Coaxial Input

1

Asynchronous USB Input

USB Type B conforming to USB Audio Class 1 or USB Audio Class 2 (user selectable)

Bluetooth

5.0 aptX HD

HDMI ARC Input

1 (eARC compatible)

Preamp Output

RCA pre-out

Headphone Output

Yes

Subwoofer Output

1 x RCA

Speaker Outputs

Yes

S/PDIF TOSLink Optical

TOSLINK: 16/24-bit 32-96kHz

S/PDIF Coaxial

Coax SPDIF: 16/24-bit 32-192kHz

HDMI eARC

PCM up to 24bit/192kHz

USB Audio

USB Audio Class 1: Up to 24-bit 96kHz (asynchronous) | USB Audio Class 2: Up to 24-bit 384kHz (asynchronous) and up to DSD-256

Bluetooth

5.0 A2DP/AVRCP supporting SBC, aptX and aptX HD codecs

RS232 Control

Yes

THD (Unweighted)

<0.002% 1kHz at 80% of rated power (8 Ohms) | <0.02% 20Hz – 20kHz at 80% of rated power

S/N Ratio (REF 1W)

>91 dB

Crosstalk @1kHz

>90

Input Sensitivity

Input A2-A4 (unbalanced) 395mV RMS

Input Impedances

Input A1 (balanced) 100 kOhm Input A2-A4 (unbalanced) 45 kOhm

Power Amp Damping Factor

>160 at 1kHz

Subwoofer Output

1 x RCA

Max Power Consumption

1200w

Standby Power Consumption

<0.5W

Dimensions (W x H x D)

115 x 430 x 341mm (4.5 x 16.9 x 13.4”)

Weight

12.8kg (28.2Lbs)

In the box

Power cords, Remote control, Welcome letter, Registration Card, Safety guide
